T1 Thermocouple Alloy Rod (Ni90/Cr10)

Formula: Ni 90/Cr 10

Form: Rod

Material: T1 Thermocouple Alloy

Commodity: Alloys

Hazard Pictogram: GHS07, GHS08

Available in 54 variations, T1 Thermocouple Alloy Rods (Ni90/Cr10) are made from a combination of copper and nickel. Their alloy composition exhibits high thermoelectric sensitivity, making it well-suited for temperature measurement applications. These rods are commonly used in industrial processes to measure high temperatures inside furnaces, engines and other hot environments. They’re also used in scientific research to precisely track temperature changes during experiments. With our wide selection, Goodfellow's T1 Thermocouple Alloy Rod meet the needs of various temperature monitoring applications.

Wishlist

Technical Data Sheet Safety Data Sheet Tolerance Properties

Health hazard/Hazardous to the ozone layer

Serious health hazard

each

Tolerances

Rod

Diameter	=<10mm	±10%
Diameter	>10mm	±5%

Material Properties for Alloys

Mechanical Properties

Element	Value
Elongation at break( % )	44
Modulus of elasticity( GPa )	186
Izod impact strength( J m⁻¹ )	108
Tensile strength( MPa )	620-780

Electrical Properties

Element	Value
Electrical resistivity( µOhmcm )	70.6
Temperature coefficient( K⁻¹ )	0.00032

Thermal Properties

Element	Value
Maximum use temperature in air( C )	1100
Melting point( C )	1420
Thermal conductivity( W m⁻¹ K⁻¹ )	19@23°C
Coefficient of thermal expansion( x10⁻⁶ K⁻¹ )	17.2@20-1000°C
