Polyurethane T1 Thermocouple Insulated Wire (Ni90/Cr10)

Formula: Ni 90/Cr 10

Form: Insulated Wire

Material: T1 Thermocouple Alloy

Commodity: Alloys

Conductor Diameter: 0.05mm

Insulation: Polyurethane

Insulation Thickness: 0.005mm

Hazard Pictogram: GHS07, GHS08

Polyurethane T1 Thermocouple Insulated Wire (Ni90/Cr10) is part of Goodfellow's wide range of insulated wires. This product comes in 15 variations that feature polyurethane insulation surrounding thermocouple alloy cores. The polyurethane provides electrical insulation and abrasion resistance, while the enclosed alloys enable temperature measurement for industrial process monitoring and scientific research. With its selection of sizes and thermocouple types, Goodfellow's Polyurethane T1 Thermocouple Insulated Wire meets diverse temperature sensing needs.

Wishlist

Technical Data Sheet Safety Data Sheet Tolerance Properties

Health hazard/Hazardous to the ozone layer

Serious health hazard

each

Tolerances

Insulated Wire

Conductor Diameter		±10%
Insulation Thickness		Nominal
Length		+5% / -1%

Material Properties for Alloys

Mechanical Properties

Element	Value
Elongation at break( % )	44
Modulus of elasticity( GPa )	186
Izod impact strength( J m⁻¹ )	108
Tensile strength( MPa )	620-780

Electrical Properties

Element	Value
Electrical resistivity( µOhmcm )	70.6
Temperature coefficient( K⁻¹ )	0.00032

Thermal Properties

Element	Value
Maximum use temperature in air( C )	1100
Melting point( C )	1420
Thermal conductivity( W m⁻¹ K⁻¹ )	19@23°C
Coefficient of thermal expansion( x10⁻⁶ K⁻¹ )	17.2@20-1000°C
