Leaded Brass Rod (Cu58/Zn39/Pb 3)

Formula: Cu 58/Zn 39/Pb 3

Form: Rod

Material: Leaded Brass

Commodity: Alloys

Hazard Pictogram: GHS08

Leaded Brass Rods (Cu58/Zn39/Pb3) are made from a copper-zinc alloy with lead additions. Available in 13 variations, they have good corrosion resistance, machinability and mechanical properties. These rods are used in applications like plumbing fittings, gears, valves and marine components. Our large range of Leaded Brass Rods (Cu58/Zn39/Pb3) enables you to meet your performance requirements for specific applications.

Wishlist

Technical Data Sheet Safety Data Sheet Tolerance Properties

Serious health hazard

each

Tolerances

Rod

Diameter	=<10mm	±10%
Diameter	>10mm	±5%

Material Properties for Alloys

Mechanical Properties

Element	Value
Elongation at break( % )	25
Modulus of elasticity( GPa )	97
Hardness - Vickers( kgf mm⁻² )	100-160
Tensile strength( MPa )	360-580

Electrical Properties

Element	Value
Electrical resistivity( µOhmcm )	6.2
Temperature coefficient( K⁻¹ )	-

Thermal Properties

Element	Value
Melting point( C )	875
Specific heat( J K⁻¹ kg⁻¹ )	380@23°C
Thermal conductivity( W m⁻¹ K⁻¹ )	123@23°C
Coefficient of thermal expansion( x10⁻⁶ K⁻¹ )	20.9@20-100°C
